A 1k? resistor and a 1uF capacitor are placed in series across a 5VPP AC source at 1kHz.

a.) What is the voltage (peak-to-peak) across the capacitor?

b.) What is the voltage (peak-to-peak) across the resistor?

c.) Why do the two above voltages not sum to 5VPP?
Is Kirchhoff’s Voltage Law (KVL) no longer relevant?
