explain the relationship between modulus of elasticity and modulus of rigidity

1: Explain the basic principles of strength of materials 2: Ider-and explain the ncepts of structural Experimentally and theoretically, compute the maximum bending momer and bending stress with a defection diagram for the given load beam. The parameters are as follows: Step 1 - First, design a beam and obtain its moment and bending stress diagrams using the software BeamBoy. The beam has the following specifications: - Length $8\mathrm{m}$ - Simply supported at $0\mathrm{m}$ and $4\mathrm{m}$ - There is a distributed load of $7.5\mathrm{kN}/\mathrm{m}$ between the two supports - There is a point load of $15\mathrm{kN}$ located at the end of the beam - When using BeamBoy, select the cross-section W10 $\times 85$ Refer to the instruction sheet for help with BeamBoy
