(Solved): Label the encrgy diagram (7 bins) and indicatc which reaction corresponds to the energy diagram. S ...

Label the encrgy diagram (7 bins) and indicatc which reaction corresponds to the energy diagram. Select the reaction that matches the energy diagram. \[ \begin{array}{l} \left(\mathrm{CH}_{3}\right)_{3} \mathrm{CCl}+\left(\mathrm{CH}_{3}\right)_{3} \mathrm{P} \longrightarrow\left(\mathrm{CH}_{3}\right)_{3} \mathrm{CP}^{+}\left(\mathrm{CH}_{3}\right)_{3} \mathrm{Cl}^{-} \\ \left(\mathrm{CH}_{3}\right)_{2} \mathrm{CHBr}+\mathrm{NaOCH}_{2} \mathrm{CH}_{3} \longrightarrow \mathrm{CH}_{2}=\mathrm{CHCH}_{3}+\mathrm{NaBr}+\mathrm{HOCH}_{2} \mathrm{CH}_{3} \\ \mathrm{CH}_{3} \mathrm{CH}_{2} \mathrm{OH}+\mathrm{HI} \longrightarrow \mathrm{CH}_{3} \mathrm{CH}_{2} \mathrm{I}+\mathrm{H}_{2} \mathrm{O} \end{array} \]
